NETWORK SYSTEM

COMMAX realizes the best performance using
the most stable chipset with the best quality.

CNU-2M3VR
    NETWORK SYSTEM

    IP BULLET CAMERACNU-2M3VR

      • Thumbnail

      FUNCTION

      • 1/ 2.8" 2Mega Pixel CMOS Progressive Scan
      • H.264 / MJPEG Dual Streaming
      • 30fps @ 1920 x 1080
      • True Day & Night (ICR)
      • f= 2.8 ~ 11 mm VF lens, F 1.2
      • Micro SD Memory Card Slot
      • 2D/3D DNR, Digital WDR
      • PoE : IEEE 802.3.af
      • ONVIF
      • IR LED : 35 pcs / 30M
      • Vandal Dome, IP66

      SPECIFICATION

      Camera
      Image Sensor 1/ 2.8" 2M Pixel CMOS
      Total Pixels No. 1952(H) x 1092(V)
      Effective Pixels No. 1920(H) x 1080(V)
      Scanning System Progressive Scan
      Minimum Illumination Color : 0.07 Lux @ F1.2 / B/W : 0 Lux (IR ON)
      S/N Ratio 50dB
      IR LED 35 pcs / 35M
      Video Output Signal IP Only
      Lens
      Focal length F=2.8~11 mm
      F no. F1.2
      Angle of View Horizontal : 92.5°(W)~29°( T )
      Vertical : 68°(W) ~ 21.7° ( T )
      Focus control Manual
      Lens / Mount Type Auto DC Iris / IR-Cut / Board Mount
      Operational
      Camera OSD English
      Day & Night yes
      D-WDR yes
      Image Enhance AGC/AE/AWB/3D DNR / DSS
      Event Notification Email, FTP, Alarm Control, Recording
      External Device 1 Sensor In / 1 Alarm Out / 1 RS-485 port
      Network
      Ethernet RJ-45 10/100 BASE-T
      Video Compression H.264, MJPEG
      Resolution 176 x 128 ~ 1920 x 1080
      Bitrate control Primary: 32Kbps~10Mbps,
      Secondary : 32Kbps~4Mbps
      Audio Compression G.711 / AAC
      Audio Communication Full Duplex
      IP IPv4, IPv6
      Protocol TCP, UDP, IGMP(Multicast),DHCP, HTTP, HTTPS, RTP, RTSP, FTP, SNMP, SMTP, UPnP, WS-Discovery, Zero Configuration, DDNS
      Security Password Protection, IP address Filtering, HTTPS(SSL) Certifications
      ONVIF ONVIF 2.x
      language English
      Viewer Web, PC, Mobile Viewer
      Environmental
      Operating Temperature -10°C ~ +50°C / Up to 85%RH
      Certifications CE, FCC, MSIP
      Power
      Power Source /
      current consumption
      12V DC / 1.5A, PoE (IEEE802.3af)
      consumption of power Max. 6W
      Mechanical
      Dimension (WxH) Ø76 x 230.3mm (Ø x H)
      Weight 800g
      IP Rating IP 66

      INSTALLATION
