CCTV SYSTEM

IP 2MP VANDAL IR DOME CAMERACNV-2M4VRS

    • Thumbnail

    FUNCTION

    • 2Megapixel IR Vandal dome Camera
    • 1/3“ Progressive Scan CMOS Image Sensor
    • Vari-focal Lens, f=2.8~12mm
    • Video streaming performance of 30fps@1920x1080
    • Superior video quality under low bitrate
    • Multi-stream, Dual-encoding
    • 12pcs of IR-LED
    • IR distance of Max. 20m
    • 1 Alarm Input / 1 Alarm Output
    • Supports Corridor mode
    • Dust & Water-proof of IP66

    SPECIFICATION

    Camera
    Image Sensor 1/2.9" Progressive Scan CMOS
    Max. Resolution 1920 x1080
    Scanning System Progressive Scan
    Min. Illumination Color 0.05 Lux, IR On 0 Lux
    IR-LED 12pcs / 15~20m
    Lens
    Focal Length f = 2.8~12mm
    Angle of View 89°(Tele) ~107°(Wide)
    Lens / Mount Type Fixed Lens/ Board Mount
    Camera Function
    Day & Night ICR
    Gain Control Auto / Manual
    White Balance Auto
    WDR D-WDR
    Digital Noise Reduction 2D/3D DNR
    Motion Detection Off / On
    Privacy Zone Masking Max. 4 Areas
    Corridor Mode Off / On
    Event Notification Email Notification
    Network
    Ethernet Ethernet 10/100 Base-T (RJ-45)
    Video Compression H.264 High/ Main/ Baseline Profile, MJPEG
    Max. Frame rate 30fps @ 1920 x 1080
    Bitrate Control CBR / VBR
    Audio Input / Output 1ch Audio Input / 1ch Audio Output
    Audio Compression G.711, RAW_PCM
    IP IPv4 / IPv6
    Protocol HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, PPPoE
    Security User Verification, Communication Encryption
    Memory Slot Micro SD/SDHC, Up to 32GB
    ONVIF Onvif 2.4
    Remote Access Web, PC, Mobile Viewer
    Environmental
    Operating Temp / Humidity -25°C ~ +55°C / 0 ~ 90%RH
    IP Rating IP66
    Power
    Input Power DC12V, PoE
    Power Consumption 5W (IR-LED Off), 7W (IR-LED On)
    Mechanical
    Color / Material White / Aluminum
    Dimension 120.3(Ø) x 112.4(H) mm
    Weight Approx. 900g

    INSTALLATION
