NETWORK SYSTEM

COMMAX realizes the best performance using
the most stable chipset with the best quality.

CNU-2M04RS
    NETWORK SYSTEM

    IP 2MP IR MINI BULLET CAMERACNU-2M04RS

      • Thumbnail

      FUNCTION

      • 2Megapixel IR Bullet Camera
      • 1/3“ Progressive Scan CMOS Image Sensor
      • Fixed Lens, f=3.6mm
      • Video streaming performance of 30fps@1920x1080
      • Superior video quality under low bitrate
      • Multi-stream, Dual-encoding
      • 2pcs of Super IR-LED
      • IR distance of Max. 30m
      • Supports Corridor mode
      • Dust & Water-proof of IP66

      SPECIFICATION

      Camera
      Image Sensor 1/3" Progressive Scan CMOS
      Max. Resolution 1920 x1080
      Scanning System Progressive Scan
      Min. Illumination Color 0.2 Lux, IR On 0 Lux
      IR-LED 2pcs / 20~30m
      Lens
      Focal Length f = 3.6mm
      Angle of View 75°
      Lens / Mount Type Fixed Lens/ Board Mount
      Camera Function
      Day & Night ICR
      Gain Control Auto / Manual
      White Balance Auto
      WDR D-WDR
      Digital Noise Reduction 2D/3D DNR
      Motion Detection Off / On
      Privacy Zone Masking Max. 4 Areas
      Corridor Mode Off / On
      Event Notification Email Notification
      Network
      Ethernet Ethernet 10/100 Base-T (RJ-45)
      Video Compression H.264 High/ Main/ Baseline Profile, MJPEG
      Max. Frame rate 30fps @ 1920 x 1080
      Bitrate Control CBR / VBR
      Audio Input / Output 1ch Audio Input / 1ch Audio Output
      Audio Compression G.711, RAW_PCM
      IP IPv4 / IPv6
      Protocol HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, PPPoE
      Security User Verification, Communication Encryption
      Memory Slot Micro SD/SDHC, Up to 32GB
      ONVIF Onvif 2.4
      Remote Access Web, PC, Mobile Viewer
      Environmental
      Operating Temp / Humidity -20°C ~ +55°C / 0 ~ 90%RH
      IP Rating IP66
      Power
      Input Power DC12V, PoE
      Power Consumption 5W (IR-LED Off), 7W (IR-LED On)
      Mechanical
      Dimension 169(L) x 70(W) x 63(Ø) mm
      Weight Approx. 631g

      INSTALLATION
