NETWORK SYSTEM

COMMAX realizes the best performance using
the most stable chipset with the best quality.

CNU-2M4VRS
    NETWORK SYSTEM

    IP 2MP IR BULLET CAMERACNU-2M4VRS

      • Thumbnail

      FUNCTION

      • 2Megapixel IR Bullet Camera
      • 1/3“ Progressive Scan CMOS Image Sensor
      • Vari-focal Lens, f=2.8~12mm
      • Video streaming performance of 30fps@1920x1080
      • Superior video quality under low bitrate
      • Multi-stream, Dual-encoding
      • 10pcs of IR-LED
      • IR distance of Max. 25m
      • Supports Corridor mode
      • Dust & Water-proof of IP66

      SPECIFICATION

      Camera
      Image Sensor 1/2.9" Progressive Scan CMOS
      Max. Resolution 1920 x1080
      Scanning System Progressive Scan
      Min. Illumination Color 0.05 Lux, B/W 0.01 Lux, IR On 0 Lux
      IR-LED 10pcs / 20~25m
      Lens
      Focal Length f = 2.8~12mm
      Angle of View 89°(Tele) ~ 35°(Wide)
      Lens / Mount Type Fixed Lens/ Board Mount
      Camera Function
      Day & Night ICR
      Gain Control Auto / Manual
      White Balance Auto
      WDR D-WDR
      Digital Noise Reduction 2D/3D DNR
      Motion Detection Off / On
      Privacy Zone Masking Max. 4 Areas
      Corridor Mode Off / On
      Event Notification Email Notification
      Network
      Ethernet Ethernet 10/100 Base-T (RJ-45)
      Video Compression H.264 High/ Main/ Baseline Profile, MJPEG
      Max. Frame rate 30fps @ 1920 x 1080
      Bitrate Control CBR / VBR
      IP IPv4 / IPv6
      Protocol HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, PPPoE
      Security User Verification, Communication Encryption
      Memory Slot Micro SD/SDHC, Up to 32GB
      ONVIF Onvif 2.4
      Remote Access Web, PC, Mobile Viewer
      Environmental
      Operating Temp / Humidity -20°C ~ +55°C / 0 ~ 90%RH
      IP Rating IP66
      Power
      Input Power DC12V, PoE
      Power Consumption 5W (IR-LED Off), 7W (IR-LED On)
      Mechanical
      Dimension 264.5(L) x 80.3(Ø) mm
      Weight Approx. 780g

      INSTALLATION
