NETWORK SYSTEM

COMMAX realizes the best performance using
the most stable chipset with the best quality.

CNP-3M12ORS
    NETWORK SYSTEM

    IP 3MP X12 IR PTZ CAMERACNP-3M12ORS

      • Thumbnail

      FUNCTION

      • 2Megapixel IR PTZ Camera
      • 1/2.8“ Progressive Scan CMOS Image Sensor
      • 12x Optical zoom (16x Digital zoom)
      • Video streaming performance of 30fps@2048x1536
      • Superior video quality under low bitrate
      • Multi-stream, Dual-encoding
      • IR distance of Max. 60m
      • Excellent low-light performance
      • Dust & Water-proof of IP66
      • Unique Appearance design

      SPECIFICATION

      Camera
      Image Sensor 1/2.8" Progressive Scan CMOS
      Max. Resolution 2048 x 1536
      Scanning System Progressive Scan
      Min. Illumination Color 0.01 Lux, B/W 0.001 Lux, IR On 0 Lux
      IR-LED 6pcs / 60m
      Lens
      Focal Length Optical 12x, f = 4.7~56.4mm
      Angle of View

      69.7°(Tele) ~ 7.56°(Wide)

      Camera Function
      Day & Night ICR
      Gain Control Auto / Manual
      WDR D-WDR
      Digital Noise Reduction 2D/3D DNR
      Motion Detection Off / On
      Digital Zoom 16x
      PTZ Function
      Pan/Tilt Range PAN : 0°~360° / TILT : -10°~90°
      Pan Speed Manual : 0.01°~180°/sec, Preset : 90°/sec
      Tilt Speed Manual : 0.01° ~ 90°/sec
      Preset 300 Preset Positions
      Tour 12 Groups
      Scan 12 Scans
      Track 6 Tracks
      Privacy Zone Masking 8 Zones
      Network
      Ethernet Ethernet 10/100 Base-T (RJ-45)
      Video Compression H.264 High/ Main/ Baseline Profile, MJPEG
      Max. Frame rate 30fps @ 2048 x 1536
      Bitrate Control CBR / VBR
      Protocol HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, PPPoE
      Security User Verification, Communication Encryption
      Memory Slot Micro SD/SDHC/SDXC, Up to 64GB
      ONVIF Onvif 2.4
      Alarm Input / Output 2 Alarm Inputs / 1 Relay Outputs
      Audio Input / Output 1ch Audio Input / 1ch Audio Output
      Audio Compression G.711, RAW_PCM
      Remote Access Web, PC, Mobile Viewer
      Environmental
      Operating Temp / Humidity -40°C ~ +60°C / 0 ~ 90%RH
      IP Rating IP66
      Power
      Input Power DC12V / 2.5A, PoE+
      Power Consumption Max. 25W
      Mechanical
      Color / Material White / Aluminum
      Dimension 321.3(H) x 222.3(D) x 146.6(Ø) mm
      Weight Approx. 1.5Kg (w/o Bracket)

      INSTALLATION
