CCTV SYSTEM

IP 2MP X22 IR PTZ CAMERACNP-2M22ORS

    • Thumbnail

    FUNCTION

    • 2Megapixel IR PTZ Camera
    • 1/2.8“ Progressive Scan CMOS Image Sensor
    • 22x Optical zoom (16x Digital zoom)
    • Video streaming performance of 30fps@1080p
    • Superior video quality under low bitrate
    • Multi-stream, Dual-encoding
    • IR distance of Max. 100m
    • Smart IR technology
    • Excellent low-light performance
    • Dust & Water-proof of IP66

    SPECIFICATION

    Camera
    Image Sensor 1/2.8" Progressive Scan CMOS
    Max. Resolution 1920 x1080
    Scanning System Progressive Scan
    Min. Illumination Color 0.02 Lux, B/W 0.002 Lux, IR On 0 Lux
    IR-LED 8pcs / 100m
    Lens
    Focal Length Optical 22x, f = 4.7~103mm
    Angle of View 58.7°(Tele) ~ 3.2°(Wide)
    Camera Function
    Day & Night ICR
    Gain Control Auto / Manual
    WDR D-WDR
    Digital Noise Reduction 2D/3D DNR
    Motion Detection Off / On
    Digital Zoom 16x
            PTZ Function
    Pan/Tilt Range PAN : 0°~360° / TILT : 0°~98°
    Pan Speed Manual : 0.01°~180°/sec, Preset : 90°/sec
    Tilt Speed Manual : 0.01° ~ 90°/sec
    Preset 255 Preset Positions
    Tour 12 Groups
    Pattern 6 Patterns
    Scan 12 Scans
    Privacy Zone Masking 8 Zones
    Network
    Ethernet Ethernet 10/100 Base-T (RJ-45)
    Video Compression H.264 High/ Main/ Baseline Profile, MJPEG
    Max. Frame rate 30fps @ 1920 x 1080
    Bitrate Control CBR / VBR
    Protocol HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, PPPoE
    Security User Verification, Communication Encryption
    Memory Slot Micro SD/SDHC/SDXC, Up to 64GB
    ONVIF Onvif 2.4
    Alarm Input / Output 7 Alarm Inputs / 2 Relay Outputs
    Audio Input / Output 1ch Audio Input / 1ch Audio Output
    Audio Compression G.711, RAW_PCM
    Remote Access Web, PC, Mobile Viewer
    Environmental
    Operating Temp / Humidity -40°C ~ +60°C / 0 ~ 90%RH
    IP Rating IP66
    Power
    Input Power AC24V / 2.5A
    Power Consumption Max. 40W
    Mechanical
    Color / Material White / Aluminum
    Dimension 204.8(Ø) x 332 mm (w/o Bracket)
    Weight Approx. 4.3Kg (w/o Bracket)

    INSTALLATION
